PREMIUM PR:O 112 FD2

THE GERMAN AUDIO STANDARD

An active full-range speaker in the classic 12″ format with a balanced sound, excellent speech intelligibility and high usable sound pressure.

Also ideal as a mid/high unit in combination with the bass PR:O 118 SUB D2 as a club PA. The built-in MultiGrips enable safe and comfortable handling.

Concept	Active 2-way loudspeaker
Power amplifier output peak	1200 W
DSP functions	Tone control (Music/Speech)
Analog input	1 x XLR/jack combo symm. (Mic/Line)
Analog output	1 x XLR-Thru symm.

technical data

Characteristics

ConceptActive 2-way loudspeaker

Cabinet principleBass reflex

Max. SPL average²124 dB

Max. SPL peak³132 dB

Max. SPL calculated⁵133 dB

Crossover frequency2.5 kHz

Frequency range -6 dB72 Hz - 16 kHz

Frequency range -10 dB62 Hz - 18 kHz

Dispersion angle -6 dB (horizontal x vertical)90° x 55°

Index

Index 2)1 x unit @ 1 m, 10 % THD, 70 Hz - 12 kHz, (EN 60268-21), half space

Index 3)1 x unit @ 1 m, 10 % THD @ 2.5 kHz, half space

Index 5)Calculated with 120 W and measured peak of 106 dB (1W/1m), half space

Components

Mid/high frequency1 x 12" cone speaker

High frequency1 x 1" compression driver

HornConstant directivity horn

Connections

Analog input1 x XLR/jack combo symm. (Mic/Line)

Analog output1 x XLR-Thru symm.

Electronical data

Power amplifierClass D - Biamped

Power amplifier output peak1200 W

Speaker protectionPeak- und RMS-Sound-Limiter (separately for HF and LMF)

DSP functionsTone control (Music/Speech)

Filter presetsFlat/Boost

Mechanical data

Cabinet features/riggingDuoTilt 3/7

Carrying handles2, MultiGrip

Cabinet materialMDF

Cabinet surfaceacrylic enamel

ColorJet black (RAL 9005)

Front grilleSteel front grille, backed with acoustic foam

Dimensions (W x H x D), metric40.5 x 59.5 x 37 cm

Dimensions (W x H x D), imperial15-15/16 x 23-7/16 x 14-9/16 inch

Weight, metric20.2 kg

Weight, imperial44.5 lbs

The built-in MultiGrips allow safe and comfortable handling and make professional rigging a breeze by simply installing the TB-45N or TB-45NQ tilt brackets on them.
